Proximity-Box
Arayüz Kutuları ve Sensörler
Proximity-Box
Arayüz Kutuları ve Sensörler
Interface Boxes And Sensors
Entegre radar teknolojisiyle ahşap, plastik veya alçıpan duvarların arkasından nesnelerin yaklaşımını ve hareket yönünü algılar.
MOBOTIXArayüz Kutuları ve Sensörler
Teknik dokümantasyon
Özellikler
Genel Özellikler
Ürün adıMX-Proximity-Box EAN 4047438025881 Supported video sources All MOBOTIX cameras ve doorstations ile MxBus connector ile firmware version 4.4.2.5x veya higher (from 14/24 series) Ambient temperature -20 ila 60°C (-4 ila 140°F) IP Sınıf IP66 (dust-proof ve resistant ila water jets) IK Sınıf Corresponds ila IK07 (protection against mechanical impacts of kadar 2 joules: 500 g at a height of 20 cm) Intended use - Not for use in areas at risk of explosions; connection (Ex area) - Connection ila MxBus only - Only in…
Ağırlık (ambalajsız)73 g Connections MxBus (2 clamps) Diameter MxBus wiring 0.6 ila 0.8 mm; recommendation: 0,8 mm J-Y(St)Y (AWG 21)
Güç beslemesi48 V DC, üzerinden camera ve MxBus
Güç tüketimi0,5 ila 1 W Frequency (Radar radiation) ~24 GHz Radiation power (EIRP) 12,59 ila 63,1 mW, typ. 31,63 mW Detection range 80° x 34° (horizontal x vertical) Individual: 0 ila 15 m (0 ila 50 ft) Automobile: 0 ila 35 m (0 ila 115 ft) Detectable movements Approaching, distancing ve general movements Recommended installation height for detecting people 100 ila 120 cm (3.3 ila 3.9 ft) Suitable materials for concealed installation It is not possible ila install the MX-Proximity-Box behind some materials since they…
Malzemeyou want ila use. LED 2x RGB; left LED: operating status; right LED: radar signal (leaving/approaching/ movement); LED intensity increases ile increasing strength of the reflected radar signal Housin PBT GF30
SertifikalarEN 60950-1:2006/A11:2009/A1:2010/A2:2013/AC:2001/A12:2011 EN 301 489-1 V2.1.1, EN 301 489-3 V1.6.1, Draft EN 301 489-3 V2.1.0 EN 300 440-1 (V1.6.1); EN 300 440-2 (V1.4.1); (Draft EN 300 440 V2.1.0) CFR 47 FCC Part 15C RSS-310 ISSUE 4
MTBF (ortalama arızasız çalışma süresi)> 80.000 saat Mitgeliefertes Zubehör 1 screwdriver, 1 plug 3 ila 5 mm, 1 plug 5 ila 7 mm, 1 MxBus cable 0.5 m/1.64 ft, 2 washers Ø 4.3 mm, 2 stainless steel wood screws 4x40 mm, 2 screw anchors S6, 1 security bit TX10
Ayrıntılı teknik dokümantasyonwww.mobotix.com > Support > Manuals Online version of this document
